SPECIFICATIONS
| STANDARD FEATURES | |
| Length | 53′ |
| Width | 8’6″, 9′, and 10′ |
| Capacity | 55 Ton over complete lower deck; 40 Ton over 15′; 35 Ton over 10′ |
| Tare Weight | Approx 22,250 Lbs Dependant on Options |
| GVWR | Approx 51,500 Kg |
| Landing Gear | 2 Speed Landing Gear |
| King Pin | Set at 13″ |
| Power Winch | Optional Heavy Duty 30,000 lbs Ramsey with Wireless Remote |
| Winches and Tie Downs | Winches, Chain Slots, and Pin Pockets |
| Tires | Michelin |
| Rims | 17.5 or 22.5: Various Steel and Aluminum Options |
| Serial Plate(s) | Canada/U.S. |
| Safety Certified | Yes |
| PAINT AND FINISH | |
| Blast Preparation | Completely Steel Shot Blasted |
| Special Coatings | Pure Zinc on Complete Outside Top To Bottom |
| Primer | PPG Epoxy Primer Inside and Out |
| Top Coat | PPG Urethane / Acrycote Systems – All Colours Available |
| Paint Cure System | Entire Trailer put in Heat Ovens for Optimal Paint Cure Hardness and Adhesion |
| Safety | Reflective Tape |
| SUSPENSION | |
| System | Ridewell RAR240 |
| Brakes | Drum or Disc |
| Axle Spread | 60″ Tridem on all model widths; 72″ Tridem on 8’6″ wide |
| Auto Slack Adjusters | Yes |
| Wheel End | Cast Hub and Drum Optional: Hubodometer – Metric or Imperial |
| LIGHTING | |
| Wiring Harness | Severe Duty Sealed Harness System |
| Lighting | Standard LED |
| PROTECTIVE FEATURES | |
| Mudflaps | Mudflap in front of hydraulic control valve 1 pair behind rear wheels |
| Impact Guard | Rear Impact Guard to meet CMVSS 223 specifications Tri-Drive Flip Neck |
| OTHER OPTIONS | |
| Tri-Drive Flip Neck Rail Road Track Kit Toolboxes Live Rolls Grouser Bars Swing-Out Wide Load Lights |
|
